| PartNumber | AM-800480RSTMQW-TA1H |
| Marca | AMPIRE |
| mărimea | 7.0 |
| Aplicație | CNS |
| Rezoluţie | 800×480 |
| Compoziţie | LCM |
| Luminozitate | 400 |
| CR | 400:1 |
| Culori | 262K |
| Iluminare de fundal | WLED |
| Interfață | LVDS |
| marca panoului | AMPIRE |
| model de panou | AM-800480RSTMQW-TA1H |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 7.0 inch |
| rezoluţie | 800(RGB)×480 , WVGA |
| modul de afișare | TN, Normally White, Transmissive |
| Zonă activă | 152.4×91.44 mm |
| contur | 165×104.44×7.61 mm |
| suprafaţă | |
| luminozitatea | 400 cd/m² (Typ.) |
| Raport de contrast | 400:1 (Typ.) |
| culorile afișajului | 262K (6-bit) |
| timp de raspuns | 5/11 (Typ.)(Tr/Td) |
| unghi de vedere | 70/70/70/60 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | 3S10PWLEDWithout Driver |
| interfață de semnal | LVDS (1 ch, 6-bit), 20 pins |
| tensiune de intrare | 3.3V (Typ.) |
| aplicarea | CNS |
| A070VW04 V3 | AUO | 7.0 | 800×480 |
| AM-800480R3TMQW-B2H | AMPIRE | 7.0 | 800×480 |
| AM-800480RCTMQW-00H | AMPIRE | 7.0 | 800×480 |
| AM-800480RSTMQW-TA1H | AMPIRE | 7.0 | 800×480 |
| AM-800480RWTMQW-TA4H | AMPIRE | 7.0 | 800×480 |
| AT070TN93 V.2 | Innolux | 7.0 | 800×480 |
| COM70T7M17ZLC | ORTUSTECH | 7.0 | 800×480 |
| DLC0700JBG-T-6 | Other | 7.0 | 1024×600 |
| LQ070Y5DG20 | SHARP | 7.0 | 800×480 |
| LTM07C382 | TOSHIBA | 7.0 | 1024×600 |
| A102VW01 V7 | AUO | 10.2 | 800×480 |
| CLAA069LA0NCW | CPT | 7.0 | 800×480 |
| CLAA080LJ01CW | CPT | 8.0 | 800×480 |
| DJ065NA-01C | Innolux | 6.5 | |
| LTA065B0F0F | TOSHIBA | 6.5 | 800×480 |
| M101GWT9 R3 | IVO | 10.1 | 1024×600 |
| PA079DS1T3 | E Ink | 7.9 | 480×234 |
| PW062XU8 | E Ink | 6.2 | 480×234 |
| TD070WGCB2 | TPO | 7.0 | 854×480 |
| TJ123NP01BA | Innolux | 12.3 | 1280×480 |
