| PartNumber | HSD040I3N1-B00 |
| Marca | HannStar |
| mărimea | 4.0 |
| Aplicație | CNS |
| Rezoluţie | 320×240 |
| Compoziţie | LCM |
| Luminozitate | 4700 |
| CR | 350:1 |
| Culori | 16.7M |
| Iluminare de fundal | WLED |
| Interfață | TTL |
| marca panoului | HannStar |
| model de panou | HSD040I3N1-B00 |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 4.0 inch |
| rezoluţie | 320(RGB)×240 , QVGA |
| modul de afișare | TN, Normally White, Transmissive |
| Zonă activă | 82.08×61.56 mm |
| contur | 112.11×80.51×8.3 mm |
| suprafaţă | |
| luminozitatea | 4700 cd/m² (Typ.) |
| Raport de contrast | 350:1 (Typ.) |
| culorile afișajului | 16.7M (8-bit), CIE193145% |
| timp de raspuns | 4/12 (Typ.)(Tr/Td) |
| unghi de vedere | 60/60/60/40 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | WLEDWithout Driver |
| interfață de semnal | Parallel RGB (1 ch, 8-bit) + SPI, 40 pins |
| tensiune de intrare | 3.3V (Typ.) |
| aplicarea | CNS |
