| PartNumber | YXD101301000-60 |
| Marca | SEBO |
| mărimea | 10.1 |
| Aplicație | CNS |
| Rezoluţie | 1024×600 |
| Compoziţie | LCM |
| Luminozitate | 1000 |
| CR | 600:1 |
| Culori | 16.2M |
| Iluminare de fundal | WLED |
| Interfață | LVDS |
| marca panoului | SEBO |
| model de panou | YXD101301000-60 |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 10.1 inch |
| rezoluţie | 1024(RGB)×600 , WSVGA |
| modul de afișare | TN, Normally White, Transmissive |
| Zonă activă | 222.72×125.28 mm |
| contur | 235×149.2×6.3 mm |
| suprafaţă | Antiglare |
| luminozitatea | 1000 cd/m² (Typ.) |
| Raport de contrast | 600:1 (Typ.) |
| culorile afișajului | 16.2M (6-bit + FRC), CIE193152% |
| timp de raspuns | 25 (Typ.)(Tr+Td) |
| unghi de vedere | 70/70/60/60 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | WLEDWithout Driver |
| interfață de semnal | LVDS (1 ch, 8-bit), 60 pins |
| tensiune de intrare | 3.3/9.6/18/-6V (Typ.)(DVDD/AVDD/VGH/VGL) |
| aplicarea | CNS |
