| PartNumber | VVX10F011B00 |
| Marca | Panasonic |
| mărimea | 10.1 |
| Aplicație | PAD |
| Rezoluţie | 1920×1200 |
| Compoziţie | LCM |
| Luminozitate | 650 |
| CR | 1000:1 |
| Culori | 16.7M |
| Iluminare de fundal | WLED |
| Interfață | eDP |
| marca panoului | Panasonic |
| model de panou | VVX10F011B00 |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 10.1 inch |
| rezoluţie | 1920(RGB)×1200 , WUXGA |
| modul de afișare | IPS, Normally Black, Transmissive |
| Zonă activă | 217.44×135.9 mm |
| contur | 228.86×152.5×4.18 mm |
| suprafaţă | Hard coating, Antireflection |
| luminozitatea | 650 cd/m² (Min.) |
| Raport de contrast | 1000:1 (Typ.) |
| culorile afișajului | 16.7M (8-bit), CIE193150% |
| timp de raspuns | 35 (Max.)(Tr+Td) |
| unghi de vedere | 80/80/80/80 (Typ.)(CR≥100)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | 10S6PWLEDEmbedded (LED Driver) |
| interfață de semnal | eDP (2 Lanes), 30 pins |
| tensiune de intrare | 3.3V (Typ.) |
| aplicarea | PAD |
