| PartNumber | VVX10F002A00 |
| Marca | Panasonic |
| mărimea | 10.1 |
| Aplicație | PAD |
| Rezoluţie | 1920×1200 |
| Compoziţie | LCM |
| Luminozitate | 450 |
| CR | 1000:1 |
| Culori | 16.7M |
| Iluminare de fundal | WLED |
| Interfață | MIPI |
| marca panoului | Panasonic |
| model de panou | VVX10F002A00 1 Compatible model |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 10.1 inch |
| rezoluţie | 1920(RGB)×1200 , WUXGA |
| modul de afișare | IPS, Normally Black, Transmissive |
| Zonă activă | 217.44×135.9 mm |
| contur | 227.1×147.1×4.13 mm |
| suprafaţă | Hard coating, Antireflection |
| luminozitatea | 450 cd/m² (Typ.) |
| Raport de contrast | 1000:1 (Typ.) |
| culorile afișajului | 16.7M (8-bit), CIE193150% |
| timp de raspuns | 30 (Max.)(Tr/Td) |
| unghi de vedere | 80/80/80/80 (Typ.)(CR≥100)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | 6S6PWLEDEmbedded (LED Driver) |
| interfață de semnal | MIPI (4 data lanes), 40 pins |
| tensiune de intrare | 3.7V (Typ.) |
| aplicarea | PAD |
