| PartNumber | LP125WH2-SPR1 |
| Marca | LG Display |
| mărimea | 12.5 |
| Aplicație | PAD |
| Rezoluţie | 1366×768 |
| Compoziţie | LCM |
| Luminozitate | 300 |
| CR | 500:1 |
| Culori | 262K |
| Iluminare de fundal | WLED |
| Interfață | eDP |
| marca panoului | LG Display |
| model de panou | LP125WH2-SPR1 |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 12.5 inch |
| rezoluţie | 1366(RGB)×768 , WXGA |
| modul de afișare | AH-IPS, Normally Black, Transmissive |
| Zonă activă | 275.59×154.94 mm |
| suprafaţă | |
| luminozitatea | 300 cd/m² (Typ.) |
| Raport de contrast | 500:1 (Min.) |
| culorile afișajului | 262K (6-bit), CIE193150% |
| timp de raspuns | 35 (Typ.)(Tr+Td) |
| unghi de vedere | 80/80/80/80 (Min.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | WLEDEmbedded (LED Driver) |
| interfață de semnal | eDP (1 Lane) |
| tensiune de intrare | 3.3V (Typ.) |
| aplicarea | PAD |
