| PartNumber | LPM070W425D |
| Marca | JDI |
| mărimea | 7.0 |
| Aplicație | PAD |
| Rezoluţie | 1200×1920 |
| Compoziţie | CELL |
| Luminozitate | 0 |
| CR | 1100:1 |
| Culori | 16.7M |
| Iluminare de fundal | No B/L |
| Interfață | MIPI |
| marca panoului | JDI |
| model de panou | LPM070W425D |
| tip panou | LTPS TFT-LCD , CELL |
| dimensiunea panoului | 7.0 inch |
| rezoluţie | 1200(RGB)×1920 , WUXGA |
| modul de afișare | IPS, Normally Black, Transmissive |
| Zonă activă | 94.5×151.2 mm |
| contur | 97.3×159.4 mm |
| suprafaţă | |
| adâncimea sticlei | 0.25+0.25 mm |
| transmisivitatea | 5.2% (Typ.)(with Polarizer) |
| Raport de contrast | 1100:1 (Typ.) |
| culorile afișajului | 16.7M (8-bit), CIE193172% |
| timp de raspuns | |
| unghi de vedere | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| driver ic | Built-in ISL97692IRTZ |
| interfață de semnal | MIPI (4 data lanes), 31 pins |
| tensiune de intrare | 1.8/3.0/3.0V (Typ.)(IOVCC/VDD/VDDP) |
| aplicarea | PAD |
