| PartNumber | LTL089CL02-002 |
| Marca | Samsung |
| mărimea | 8.9 |
| Aplicație | PAD |
| Rezoluţie | 1920×1200 |
| Compoziţie | LCM |
| Luminozitate | 450 |
| CR | 900:1 |
| Culori | 262K |
| Iluminare de fundal | WLED |
| Interfață | MIPI |
| marca panoului | SAMSUNG |
| model de panou | LTL089CL02-002 |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 8.9 inch |
| rezoluţie | 1920(RGB)×1200 , WUXGA |
| modul de afișare | PLS, Normally Black, Transmissive |
| Zonă activă | 191.52×119.7 mm |
| contur | 203.5×135.9×5.2 mm |
| suprafaţă | Glare (Haze 0%), Hard coating (2H) |
| luminozitatea | 450 cd/m² (Typ.) |
| Raport de contrast | 900:1 (Typ.) |
| culorile afișajului | 262K (6-bit) |
| timp de raspuns | 16 (Typ.)(Tr+Td) |
| unghi de vedere | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | 7S5PWLEDWithout Driver |
| interfață de semnal | MIPI (4 data lanes), 45 pins |
| tensiune de intrare | 3.3V (Typ.) |
| aplicarea | PAD |
