| PartNumber | LQ070M1SX01 |
| Marca | SHARP |
| mărimea | 7.0 |
| Aplicație | PAD |
| Rezoluţie | 1200×1920 |
| Compoziţie | LCM |
| Luminozitate | 400 |
| CR | 2000:1 |
| Culori | 16.7M |
| Iluminare de fundal | WLED |
| Interfață | MIPI |
| marca panoului | SHARP |
| model de panou | LQ070M1SX01 |
| tip panou | IGZO TFT-LCD , LCM |
| dimensiunea panoului | 7.0 inch |
| rezoluţie | 1200(RGB)×1920 , WUXGA |
| modul de afișare | ASV, Normally Black, Transmissive |
| Zonă activă | 94.5×151.2 mm |
| contur | 99.7×159.85×1.925 mm |
| suprafaţă | Clear, Hard coating |
| luminozitatea | 400 cd/m² (Typ.) |
| Raport de contrast | 2000:1 (Typ.) |
| culorile afișajului | 16.7M (8-bit), CIE193150% |
| timp de raspuns | 9/13 (Typ.)(Tr/Td) |
| unghi de vedere | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | 9S2PWLEDWithout Driver |
| interfață de semnal | MIPI (2 data lanes), 71 pins |
| tensiune de intrare | 1.8/3.0/5.5/-5.5V (Typ.)(VDDIO/VDD/VSP/VSN) |
| aplicarea | PAD |
