| PartNumber | LPM089A001A |
| Marca | JDI |
| mărimea | 8.9 |
| Aplicație | PAD |
| Rezoluţie | 2560×1600 |
| Compoziţie | LCM |
| Luminozitate | 500 |
| CR | 1200:1 |
| Culori | 16.7M |
| Iluminare de fundal | WLED |
| Interfață | MIPI |
| marca panoului | JDI |
| model de panou | LPM089A001A 2 Compatible model |
| tip panou | LTPS TFT-LCD , LCM |
| dimensiunea panoului | 8.9 inch |
| rezoluţie | 2560(RGB)×1600 , WQXGA |
| modul de afișare | IPS, Normally Black, Transmissive |
| Zonă activă | 192×120 mm |
| contur | 197.6×129.6×3.43 mm |
| suprafaţă | |
| luminozitatea | 500 cd/m² (Typ.) |
| Raport de contrast | 1200:1 (Typ.) |
| culorile afișajului | 16.7M (8-bit), CIE193172% |
| timp de raspuns | |
| unghi de vedere | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | 6S6PWLEDWithout Driver |
| interfață de semnal | MIPI (2 ch, 4 data lanes), 61 pins |
| tensiune de intrare | 1.8/3.3V (Typ.)(VDDIO/VBAT) |
| aplicarea | PAD |
| B089AW01 V3 | AUO | 8.9 | 1024×600 |
| HT089WX1-100 | HYDIS | 8.9 | 1280×768 |
| LJ089MB2S01 | SHARP | 8.9 | 640×400 |
| LPM089A001A | JDI | 8.9 | 2560×1600 |
| LQ089B1LS11 | SHARP | 8.9 | 1280×600 |
| LT089AC29000 | TOSHIBA | 8.9 | 1280×768 |
| LTL089CL02-001 | Samsung | 8.9 | 1920×1200 |
| LTN089NT01 | Samsung | 8.9 | 1024×600 |
| N089L6-L02 | Innolux | 8.9 | 1024×600 |
| NL10260BC19-01D | NLT | 8.9 | 1024×600 |
| B080XAN03.0 | AUO | 7.9 | 768×1024 |
| B101UAN01.C | AUO | 10.1 | 1920×1200 |
| BP101WX1-400 | BOE | 10.1 | 1280×800 |
| HJ070IA-01I | Innolux | 7.0 | 1024×600 |
| HJ070IA-04K | Innolux | 7.0 | 800×1280 |
| HSD101PHW1-A00 | HannStar | 10.1 | 1366×768 |
| HT121WX2-211 | HYDIS | 12.1 | 1280×800 |
| HV121WX4-110 | HYDIS | 12.1 | 1280×800 |
| LP125WH2-SPT1 | LG Display | 12.5 | 1366×768 |
| N101ICG-L21 Rev.A1 | Innolux | 10.1 | 1280×800 |
