| PartNumber | LTN089NT01 |
| Marca | Samsung |
| mărimea | 8.9 |
| Aplicație | MP4 |
| Rezoluţie | 1024×600 |
| Compoziţie | LCM |
| Luminozitate | 200 |
| CR | 500:1 |
| Culori | 262K/16.2M |
| Iluminare de fundal | WLED |
| Interfață | LVDS |
| marca panoului | SAMSUNG |
| model de panou | LTN089NT01 |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 8.9 inch |
| rezoluţie | 1024×600(RGB) , WSVGA |
| modul de afișare | TN, Normally White, Transmissive |
| Zonă activă | 195.072×113.4 mm |
| contur | 213.36×129.55×5.45 mm |
| suprafaţă | |
| luminozitatea | 200 cd/m² (Typ.) |
| Raport de contrast | 500:1 (Typ.) |
| culorile afișajului | 262K/16.2M (6-bit / 6-bit + FRC), CIE193145% |
| timp de raspuns | 16 (Typ.)(Tr+Td) |
| unghi de vedere | 50/50/25/40 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | 6S4PWLEDEmbedded (LED Driver) |
| interfață de semnal | LVDS (1 ch, 6/8-bit), 40 pins |
| tensiune de intrare | 3.3V (Typ.) |
| aplicarea | MP4 |
