| PartNumber | CLAA070WP06G XG |
| Marca | CPT |
| mărimea | 7.0 |
| Aplicație | PAD |
| Rezoluţie | 800×1280 |
| Compoziţie | LCM |
| Luminozitate | 400 |
| CR | 800:1 |
| Culori | 16.7M |
| Iluminare de fundal | WLED |
| Interfață | MIPI |
| marca panoului | CPT |
| model de panou | CLAA070WP06G XG |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 7.0 inch |
| rezoluţie | 800(RGB)×1280 , WXGA |
| modul de afișare | HFFS, Normally Black, Transmissive |
| Zonă activă | 94.2×150.72 mm |
| contur | 104.32×161.67×4.05 mm |
| suprafaţă | Hard coating (3H) |
| luminozitatea | 400 cd/m² (Typ.) |
| Raport de contrast | 800:1 (Typ.) |
| culorile afișajului | 16.7M (6-bit + Hi-FRC), CIE193160% |
| timp de raspuns | 30 (Typ.)(Tr+Td) |
| unghi de vedere | 85/85/85/85 (Min.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | 5S5PWLEDWithout Driver |
| interfață de semnal | MIPI (4 data lanes), 34 pins |
| tensiune de intrare | 1.8/3.3V (Typ.)(VCCI/VDDI) |
| aplicarea | PAD |
| CLAA070JA1BCW | CPT | 7.0 | 480×234 |
| CLAA070LB01CW | CPT | 7.0 | 800×480 |
| CLAA070LC0FCT | CPT | 7.0 | 800×480 |
| CLAA070LFA1 CW | CPT | 7.0 | 800×480 |
| CLAA070LFB1 CW | CPT | 7.0 | 800×480 |
| CLAA070LH01AW | CPT | 7.0 | 800×480 |
| CLAA070ND22CW | CPT | 7.0 | 1024×600 |
| CLAA070ND23CW | CPT | 7.0 | 1024×600 |
| CLAA070NJ05CW | CPT | 7.0 | 1024×600 |
| CLAA070WP06 XG | CPT | 7.0 | 800×1280 |
| CLAA070WP06 XG | CPT | 7.0 | 800×1280 |
| CLAA101WJ02 | CPT | 10.1 | 1366×768 |
| F101NWN7-0 | IVO | 10.1 | 1920×1200 |
| LP079X01-SMAV | LG Display | 7.9 | 768×1024 |
| LP101WH4-SLP2 | LG Display | 10.1 | 1366×768 |
| LPM070W425D | JDI | 7.0 | 1200×1920 |
| LTL089CL02-W02 | Samsung | 8.9 | 1920×1200 |
| N080ICE-GB0 Rev.A0 | Innolux | 8.0 | 800×1280 |
| N080ICE-GB1 | Innolux | 8.0 | 800×1280 |
| TV080X0M-NS0 | BOE | 8.0 | 768×1024 |
