| PartNumber | VVX11F009G00 |
| Marca | Panasonic |
| mărimea | 11.6 |
| Aplicație | PAD |
| Rezoluţie | 1920×1080 |
| Compoziţie | LCM |
| Luminozitate | 570 |
| CR | 1000:1 |
| Culori | 16.7M |
| Iluminare de fundal | WLED |
| Interfață | eDP |
| marca panoului | Panasonic |
| model de panou | VVX11F009G00 |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 11.6 inch |
| rezoluţie | 1920(RGB)×1080 , FHD |
| modul de afișare | IPS-Pro, Normally Black, Transmissive |
| Zonă activă | 256.896×144.504 mm |
| contur | 268.896×166.564 mm |
| suprafaţă | Antiglare |
| luminozitatea | 570 cd/m² (Typ.) |
| Raport de contrast | 1000:1 (Typ.) |
| culorile afișajului | 16.7M (8-bit), CIE193172% |
| timp de raspuns | 26 (Typ.)(Tr+Td) |
| unghi de vedere | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | 7S5PWLEDEmbedded (LED Driver) |
| interfață de semnal | eDP (2 Lanes), 30 pins |
| tensiune de intrare | 3.3V (Typ.) |
| aplicarea | PAD |
