AT080TN52 V.1

AT080TN52 V.1
AT080TN52 V.1
AT080TN52 V.1
AT080TN52 V.1 thumb AT080TN52 V.1 thumb AT080TN52 V.1 thumb
Marca
Innolux
mărimea
8.0
Aplicație
DPF
Rezoluţie
800×600
Compoziţie
LCM
Luminozitate
250
CR
500:1
Culori
262K/16.2M
Iluminare de fundal
WLED
Interfață
TTL
In Stock
277
Specificații

PartNumber AT080TN52 V.1
MarcaInnolux
mărimea8.0
AplicațieDPF
Rezoluţie800×600
CompoziţieLCM
Luminozitate250
CR500:1
Culori262K/16.2M
Iluminare de fundalWLED
InterfațăTTL
marca panouluiINNOLUX
model de panouAT080TN52 V.1 1 Compatible model
tip panou a-Si TFT-LCD , LCM
dimensiunea panoului8.0 inch
rezoluţie800(RGB)×600 , SVGA
modul de afișareTN, Normally White, Transmissive
Zonă activă162×121.5 mm
contur183×141 mm
suprafaţăAntiglare
luminozitatea250 cd/m² (Typ.)
Raport de contrast500:1 (Typ.)
culorile afișajului262K/16.2M (6-bit / 6-bit + Dithering)
timp de raspuns10/15 (Typ.)(Tr/Td)
unghi de vedere70/70/50/70 (Typ.)(CR≥10)(L/R/U/D)
tip lampa3S9PWLEDWithout Driver
interfață de semnalParallel RGB (1 ch, 6/8-bit), 50 pins
tensiune de intrare3.3/10.4/16.0/-7.0V (Typ.)(VCC/AVDD/VGH/VGL)
rohs:
aplicareaDPF
