| PartNumber | LSA40AT9001 |
| Marca | Innolux |
| mărimea | 10.4 |
| Aplicație | DPF |
| Rezoluţie | 800×600 |
| Compoziţie | LCM |
| Luminozitate | 250 |
| CR | 500:1 |
| Culori | 262K/16.2M |
| Iluminare de fundal | WLED |
| Interfață | TTL |
| marca panoului | CHIMEI INNOLUX |
| model de panou | LSA40AT9001 |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 10.4 inch |
| rezoluţie | 800(RGB)×600 , SVGA |
| modul de afișare | TN, Normally White, Transmissive |
| Zonă activă | 211.2×158.4 mm |
| contur | 228.4×175.4×6.2 mm |
| suprafaţă | Hard coating (3H) |
| luminozitatea | 250 cd/m² (Typ.) |
| Raport de contrast | 500:1 (Typ.) |
| culorile afișajului | 262K/16.2M (6-bit / 6-bit + Dithering), CIE193150% |
| timp de raspuns | 10/15 (Typ.)(Tr/Td) |
| unghi de vedere | 70/70/50/60 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | 3S12PWLEDWithout Driver |
| interfață de semnal | Parallel RGB (1 ch, 6/8-bit), 60 pins |
| tensiune de intrare | 3.3/10.5V (Typ.)(VCC/AVDD) |
| aplicarea | DPF |
