| PartNumber | A080SN01 V0 |
| Marca | AUO |
| mărimea | 8.0 |
| Aplicație | DPF |
| Rezoluţie | 800×600 |
| Compoziţie | LCM |
| Luminozitate | 200 |
| CR | 400:1 |
| Culori | 262K/16.7M |
| Iluminare de fundal | WLED |
| Interfață | TTL |
| marca panoului | AUO |
| model de panou | A080SN01 V0 |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 8.0 inch |
| rezoluţie | 800(RGB)×600 , SVGA |
| modul de afișare | TN, Normally White, Transmissive |
| Zonă activă | 162×121.5 mm |
| contur | 183×141 mm |
| suprafaţă | Antiglare |
| luminozitatea | 200 cd/m² (Typ.) |
| Raport de contrast | 400:1 (Typ.) |
| culorile afișajului | 262K/16.7M (6-bit / 6-bit + Dithering) |
| timp de raspuns | 4/16 (Typ.)(Tr/Td) |
| unghi de vedere | 70/70/50/65 (Typ.)(CR≥10)(L/R/U/D) |
| tip lampa | 3S8PWLEDWithout Driver |
| interfață de semnal | TTL (1 ch, 6/8-bit) + SPI, 60 pins |
| tensiune de intrare | 3.3/11.6/15/-6.75V (Typ.)(VCC/AVDD/VGH/VGL) |
| aplicarea | DPF |
