| PartNumber | A080SN03 V2 |
| Marca | AUO |
| mărimea | 8.0 |
| Aplicație | DPF |
| Rezoluţie | 800×600 |
| Compoziţie | CELL |
| Luminozitate | 0 |
| CR | 500:1 |
| Culori | 16.2M |
| Iluminare de fundal | No B/L |
| Interfață | TTL |
| marca panoului | AUO |
| model de panou | A080SN03 V2 |
| tip panou | a-Si TFT-LCD , CELL |
| dimensiunea panoului | 8.0 inch |
| rezoluţie | 800×600(RGB) , SVGA |
| modul de afișare | TN, Normally White, Transmissive |
| Zonă activă | 162×121.5 mm |
| contur | 170.1×132.3 mm |
| suprafaţă | Antiglare, Hard coating (3H) |
| adâncimea sticlei | 0.50+0.50 mm |
| transmisivitatea | 4.88% (Typ.)(with Polarizer) |
| Raport de contrast | 500:1 (Typ.) |
| culorile afișajului | 16.2M (6-bit + Dithering), CIE193150% |
| timp de raspuns | 12/18 (Typ.)(Tr/Td) |
| unghi de vedere | 70/70/60/65 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| interfață de semnal | TTL (1 ch, 8-bit) + SPI, 60 pins |
| tensiune de intrare | 3.3/5/-5/14/-14V (Typ.)(VDDIO/VDPA/VDNA/VGH/VGL) |
| aplicarea | DPF |
