| PartNumber | LH350WV2-SH02 |
| Marca | LG Display |
| mărimea | 3.5 |
| Aplicație | MPH |
| Rezoluţie | 480×800 |
| Compoziţie | CELL |
| Luminozitate | 0 |
| CR | 800:1 |
| Culori | 16.7M |
| Iluminare de fundal | No B/L |
| Interfață | |
| marca panoului | LG Display |
| model de panou | LH350WV2-SH02 |
| tip panou | a-Si TFT-LCD , CELL |
| dimensiunea panoului | 3.5 inch |
| rezoluţie | 480(RGB)×800 , WVGA |
| modul de afișare | IPS, Normally Black, Transmissive |
| Zonă activă | 45.36×75.6 mm |
| contur | 48.96×83×0.45 mm |
| suprafaţă | Without Polarizer |
| adâncimea sticlei | 0.225+0.225 mm |
| transmisivitatea | 3.5% (Typ.)(with Polarizer) |
| Raport de contrast | 800:1 (Typ.) |
| culorile afișajului | 16.7M , CIE193176% |
| timp de raspuns | 35 (Typ.)(Tr+Td) |
| unghi de vedere | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| driver ic | Suggest LGDP4572 |
| aplicarea | MPH |
| EL160.80.50 IN | Lumineq | 3.5 | 160×80 |
| LH350H01-FD01 | LG Display | 3.5 | 320×480 |
| LH350WS1-SD01 | LG Display | 3.5 | 640×960 |
| LH350WS1-SD02 | LG Display | 3.5 | 640×960 |
| LH350WS1-SH02 | LG Display | 3.5 | 640×960 |
| LH350WV2-SH02 | LG Display | 3.5 | 480×800 |
| LH350WV3-SH01 | LG Display | 3.5 | 480×854 |
| LQ035NC211 | Innolux | 3.5 | 320×240 |
| LQ035Q3DG01 | SHARP | 3.5 | 320×240 |
| TX09D40VM3CBA | KOE | 3.5 | 240×320 |
| AMS347FF01 | Samsung | 3.5 | 360×640 |
| LH350H01-FD01 | LG Display | 3.5 | 320×480 |
| LMS501KF03 | Samsung | 5.0 | 480×800 |
| LS026Q3DX01 | SHARP | 2.6 | 240×320 |
| LTP283QV-F03 | Samsung | 2.8 | 240×320 |
| OEL9M0039-R-E | Other | 1.5 | 128×128 |
| PJ050IA-14A | Innolux | 5.0 | 720×1280 |
| TM024HDH36 | Tianma | 2.4 | 240×320 |
| TP241MC01G | Neoview Kolon | 2.4 | 240×320 |
| TX06D15VM1EAA | KOE | 2.2 | 176×220 |
