| PartNumber | LH350H01-FD01 |
| Marca | LG Display |
| mărimea | 3.5 |
| Aplicație | MPH |
| Rezoluţie | 320×480 |
| Compoziţie | LCM |
| Luminozitate | 450 |
| CR | 150:1 |
| Culori | 16.7M |
| Iluminare de fundal | WLED |
| Interfață | MIPI |
| marca panoului | LG Display |
| model de panou | LH350H01-FD01 |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 3.5 inch |
| rezoluţie | 320(RGB)×480 , HVGA |
| modul de afișare | TN, Normally White, Transflective |
| Zonă activă | 49.92×74.88 mm |
| contur | 55.14×82.84×1.85 mm |
| suprafaţă | |
| luminozitatea | 450 cd/m² (Typ.) |
| Raport de contrast | 150:1 (Typ.)(Transmissive) |
| culorile afișajului | 16.7M (8-bit), CIE193150% |
| timp de raspuns | 35 (Typ.)(Tr+Td) |
| unghi de vedere | 60/60/60/45 (Typ.)(CR≥5)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | 6S1PWLEDWithout Driver |
| interfață de semnal | MIPI (2 data lanes), 20 pins |
| tensiune de intrare | 3.0/5.672/1.8V (Typ.)(VDDC/VDDA/LO_VCC) |
| aplicarea | MPH |
| A035VL01 V6 | AUO | 3.5 | 800×480 |
| AMS347FF01 | Samsung | 3.5 | 360×640 |
| CT035TN02 | Innolux | 3.5 | 320×480 |
| LH350H01-FD01 | LG Display | 3.5 | 320×480 |
| LH350H01-FD01-A41 | LG Display | 3.5 | 320×480 |
| LH350H02-FD02 | LG Display | 3.5 | 320×480 |
| LH350WS1-SD02 | LG Display | 3.5 | 640×960 |
| LTM035A776B | TOSHIBA | 3.5 | 240×320 |
| TCG035QVLPDANN-GN50 | Kyocera | 3.5 | 320×240 |
| TX09D83VM3CEA | KOE | 3.5 | 240×320 |
| AMS369FG06-0 | Samsung | 3.7 | 480×800 |
| AMS369FG07-002 | Samsung | 3.7 | 480×800 |
| AMS465GS53 | Samsung | 4.7 | 720×1280 |
| LH550WF1-SD01 | LG Display | 5.5 | 1080×1920 |
| LMS340KC01-001 | Samsung | 3.4 | 720×480 |
| LQ050T1SX05(G) | SHARP | 5.0 | 1080×1920 |
| LS028B7UX01 | SHARP | 2.8 | 240×400 |
| LS037V7DD06R | SHARP | 3.7 | 480×640 |
| OEL9M0039-R-E | Other | 1.5 | 128×128 |
| TM028HBHG02 | Tianma | 2.8 | 240×320 |
