| PartNumber | CT035TN02 |
| Marca | Innolux |
| mărimea | 3.5 |
| Aplicație | MPH |
| Rezoluţie | 320×480 |
| Compoziţie | LCM |
| Luminozitate | 320 |
| CR | 500:1 |
| Culori | 65K/262K |
| Iluminare de fundal | WLED |
| Interfață | CPU/RGB/SPI |
| marca panoului | CHIMEI INNOLUX |
| model de panou | CT035TN02 |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 3.5 inch |
| rezoluţie | 320(RGB)×480 , HVGA |
| modul de afișare | IPS, Normally Black, Transmissive |
| Zonă activă | 48.96×73.44 mm |
| contur | 54.76×85.24×2.1 mm |
| suprafaţă | |
| luminozitatea | 320 cd/m² (Typ.) |
| Raport de contrast | 500:1 (Typ.) |
| culorile afișajului | 65K/262K , CIE193170% |
| timp de raspuns | 30 (Typ.)(Tr+Td) |
| unghi de vedere | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | 1S5PWLEDWithout Driver |
| interfață de semnal | CPU/RGB/SPI, 50 pins |
| tensiune de intrare | 2.8/2.8V (Typ.)(VDD3/VCI) |
| aplicarea | MPH |
