| PartNumber | LS030Y3DX01 |
| Marca | SHARP |
| mărimea | 3.0 |
| Aplicație | MPH |
| Rezoluţie | 480×800 |
| Compoziţie | LCM |
| Luminozitate | 500 |
| CR | 500:1 |
| Culori | 16.7M |
| Iluminare de fundal | WLED |
| Interfață | TTL |
| marca panoului | SHARP |
| model de panou | LS030Y3DX01 |
| tip panou | CG-Silicon , LCM |
| dimensiunea panoului | 3.0 inch |
| rezoluţie | 480(RGB)×800 , WVGA |
| modul de afișare | ASV, Normally Black, Transmissive |
| Zonă activă | 38.88×64.8 mm |
| contur | 45.6×76.4 mm |
| suprafaţă | |
| luminozitatea | 500 cd/m² (Typ.) |
| Raport de contrast | 500:1 (Typ.) |
| culorile afișajului | 16.7M (8-bit), CIE193175% |
| timp de raspuns | 11/24 (Typ.)(Tr/Td) |
| unghi de vedere | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | 1S6PWLEDWithout Driver |
| interfață de semnal | Parallel RGB (1 ch, 8-bit) + SPI, 49 pins |
| tensiune de intrare | 2.8/2.8V (Typ.)(VDDIO/VCC) |
| aplicarea | MPH |
| C-51505NFJ-SLW-AIN | Kyocera | 3.0 | 20×2 |
| EJ030NC-02A | Innolux | 3.0 | |
| LS030B3UW01 | SHARP | 3.0 | 240×400 |
| LS030B3UX01D | SHARP | 3.0 | 240×400 |
| LS030B3UX07 | SHARP | 3.0 | 240×400 |
| LS030Q7DH01 | SHARP | 3.0 | 240×320 |
| LS030Y3DX01 | SHARP | 3.0 | 480×800 |
| LS030Y7PW01 | SHARP | 3.0 | |
| TFTMD030011 | JDI | 3.0 | 720×480 |
| TM030LBHT1 | Tianma | 3.0 | 240×400 |
| AMS395GB04 | Samsung | 4.0 | 360×640 |
| BB050HDG-T40 | BOE | 5.0 | 720×1280 |
| HSD015F4N2-B | HannStar | 1.5 | 128×128 |
| LS028B8PX05 | SHARP | 2.8 | 240×400 |
| LS050T1SX01 | SHARP | 5.0 | 1080×1920 |
| LS059T1SX01 | SHARP | 5.9 | 1080×1920 |
| LS063K3SX01 | SHARP | 6.3 | 720×1280 |
| TFT240320-237-E | Other | 2.8 | 240×320 |
| TM020HDZ05 | Tianma | 2.0 | 240×320 |
| TM022HDH31 | Tianma | 2.2 | 240×320 |
