| PartNumber | PJ055IA-14C |
| Marca | Innolux |
| mărimea | 5.5 |
| Aplicație | MPH |
| Rezoluţie | 1080×1920 |
| Compoziţie | LCM |
| Luminozitate | 450 |
| CR | 1000:1 |
| Culori | 16.7M |
| Iluminare de fundal | WLED |
| Interfață | MIPI |
| marca panoului | INNOLUX |
| model de panou | PJ055IA-14C |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 5.5 inch |
| rezoluţie | 1080(RGB)×1920 , FHD |
| modul de afișare | AAS, Normally Black, Transmissive |
| Zonă activă | 68.04×120.96 mm |
| contur | 70.44×70.4413×1.4 mm |
| suprafaţă | Glare (Haze 0%), Hard coating |
| luminozitatea | 450 cd/m² (Typ.) |
| Raport de contrast | 1000:1 (Typ.) |
| culorile afișajului | 16.7M (8-bit), CIE193171% |
| timp de raspuns | 10/15 (Typ.)(Tr/Td) |
| unghi de vedere | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | 7S2PWLEDWithout Driver |
| interfață de semnal | MIPI (4 data lanes), 40 pins |
| tensiune de intrare | 1.8/5.7/-5.7V (Typ.)(IOVCC/VSP/VSN) |
| aplicarea | MPH |
