| PartNumber | DX08D11VM0AAA |
| Marca | KOE |
| mărimea | 3.0 |
| Aplicație | MPH |
| Rezoluţie | 480×800 |
| Compoziţie | LCM |
| Luminozitate | 400 |
| CR | 400:1 |
| Culori | 262K/16.7M |
| Iluminare de fundal | WLED |
| Interfață | TTL |
| marca panoului | HITACHI |
| model de panou | DX08D11VM0AAA |
| tip panou | LTPS TFT-LCD , LCM |
| dimensiunea panoului | 3.0 inch |
| rezoluţie | 480(RGB)×800 , WVGA |
| modul de afișare | IPS, Normally Black, Transmissive |
| Zonă activă | 38.88×64.8 mm |
| contur | 45.6×76.4 mm |
| suprafaţă | |
| luminozitatea | 400 cd/m² (Typ.) |
| Raport de contrast | 400:1 (Typ.) |
| culorile afișajului | 262K/16.7M (6-bit / 6-bit + Hi-FRC), CIE193171% |
| timp de raspuns | 35 (Typ.)(Tr+Td) |
| unghi de vedere | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | 1S6PWLEDWithout Driver |
| interfață de semnal | Parallel RGB (1 ch, 6/8-bit) + SPI, 49 pins |
| tensiune de intrare | 1.8/2.8/2.8V (Typ.)(IOVCC/VCC/VCI) |
| aplicarea | MPH |
