| PartNumber | AL2004A |
| Marca | Other |
| mărimea | 3.0 |
| Aplicație | |
| Rezoluţie | 20×4 |
| Compoziţie | OLED |
| Luminozitate | |
| CR | |
| Culori | Mono(White) |
| Iluminare de fundal | self |
| Interfață | CPU |
| marca panoului | Amson |
| model de panou | AL2004A |
| tip panou | PM-OLED , OLED |
| dimensiunea panoului | 3.0 inch |
| format de afișare | 20 characters × 4 lines |
| afișează fonturi | 5×7 dots + cursor |
| dimensiunea caracterului | 2.97×4.77 mm |
| pasul caracterului | 3.55×5.35 mm |
| Zonă activă | 70.42×20.82 mm |
| zona rama | 72.42×22.82 mm |
| contur | 98×60×9.7 mm |
| luminozitatea | |
| Raport de contrast | |
| culorile afișajului | Mono(White) |
| driver ic | Built-in KS0066 |
| interfață de semnal | 8-bit parallel, 16 pins |
| tensiune de intrare | 3.3V (Typ.) |
