| PartNumber | TCG035QVLPDANN-GN50 |
| Marca | Kyocera |
| mărimea | 3.5 |
| Aplicație | IA |
| Rezoluţie | 320×240 |
| Compoziţie | LCM |
| Luminozitate | 1000 |
| CR | 1000:1 |
| Culori | 16.7M |
| Iluminare de fundal | WLED |
| Interfață | TTL |
| marca panoului | Kyocera |
| model de panou | TCG035QVLPDANN-GN50 |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 3.5 inch |
| rezoluţie | 320(RGB)×240 , QVGA |
| modul de afișare | TN, Normally White, Transmissive |
| Zonă activă | 70.56×52.92 mm |
| contur | 76.9×63.9×5.1 mm |
| suprafaţă | Glare (Haze 0%) |
| luminozitatea | 1000 cd/m² (Typ.) |
| Raport de contrast | 1000:1 (Typ.) |
| culorile afișajului | 16.7M (8-bit) |
| timp de raspuns | 8/22 (Typ.)(Tr/Td) |
| unghi de vedere | 80/80/80/60 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | 2 stringsWLEDWithout Driver |
| interfață de semnal | Parallel RGB (1 ch, 8-bit) + SPI, 50 pins |
| tensiune de intrare | 3.3V (Typ.) |
| aplicarea | IA |
