| PartNumber | H345VW01 V0 |
| Marca | AUO |
| mărimea | 3.5 |
| Aplicație | MPH |
| Rezoluţie | 480×800 |
| Compoziţie | LCM |
| Luminozitate | 320 |
| CR | 500:1 |
| Culori | 16.7M |
| Iluminare de fundal | WLED |
| Interfață | MIPI |
| marca panoului | AUO |
| model de panou | H345VW01 V0 |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 3.5 inch |
| rezoluţie | 480(RGB)×800 , WVGA |
| modul de afișare | VA, Normally Black, Transmissive |
| Zonă activă | 45.072×75.12 mm |
| contur | 49.02×83.52 mm |
| suprafaţă | |
| luminozitatea | 320 cd/m² (Typ.) |
| Raport de contrast | 500:1 (Min.) |
| culorile afișajului | 16.7M (8-bit), CIE193170% |
| timp de raspuns | 50/50 (Max.)(Tr/Td) |
| unghi de vedere | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | 1S6PWLEDWithout Driver |
| interfață de semnal | MIPI (2 data lanes), 24 pins |
| tensiune de intrare | 1.8/2.8V (Typ.)(VDDI/VDD) |
| aplicarea | MPH |
| 35HVE1H | SII | 3.5 | 320×480 |
| DLC0350BMG-1 | Other | 3.5 | 240×320 |
| ET035009DH6 | EDT | 3.5 | 320×240 |
| H345VW01 V0 | AUO | 3.5 | 480×800 |
| LQ035Q5DG11 | SHARP | 3.5 | 320×240 |
| NL2432HC22-41K | NLT | 3.5 | 240×320 |
| PD035QX1 | E Ink | 3.5 | 240×320 |
| PJ035MA-02A | Innolux | 3.5 | 320×480 |
| TM035KDH16-09 | Tianma | 3.5 | 320×240 |
| TX09D83VM3CEA | KOE | 3.5 | 240×320 |
| AMS300FW01-0 | Samsung | 3.0 | 240×400 |
| GCX141AKM-E | SONY | 3.2 | 240×400 |
| H347QN02 V0 | AUO | 3.5 | 320×480 |
| H380VW01 V2 | AUO | 3.8 | 480×800 |
| HSD060FMW1-C00 | HannStar | 6.0 | 540×960 |
| LB020Q01-A1 | LG Display | 2.0 | 320×240 |
| LH350H01-FD01 | LG Display | 3.5 | 320×480 |
| LMS501KF03 | Samsung | 5.0 | 480×800 |
| LQ024B7UD01 | SHARP | 2.4 | 160×240 |
| TM028HDH21 | Tianma | 2.8 | 240×320 |
