| PartNumber | LQ024B7UD01 |
| Marca | SHARP |
| mărimea | 2.4 |
| Aplicație | MPH |
| Rezoluţie | 160×240 |
| Compoziţie | LCM |
| Luminozitate | 28 |
| CR | 110:1 |
| Culori | 65K |
| Iluminare de fundal | WLED |
| Interfață | CPU |
| marca panoului | SHARP |
| model de panou | LQ024B7UD01 |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 2.4 inch |
| rezoluţie | 160(RGB)×240 , HQVGA |
| modul de afișare | TN, Normally White, Transflective |
| Zonă activă | 33.6×50.4 mm |
| contur | 41.8×66.6 mm |
| suprafaţă | Hard coating (3H) |
| luminozitatea | 28 cd/m² (Typ.) |
| Raport de contrast | 110:1 (Typ.)(Transmissive)12:1 (Typ.)(Reflective) |
| culorile afișajului | 65K |
| timp de raspuns | 30/50 (Typ.)(Tr/Td) |
| unghi de vedere | 50/50/60/50 (Typ.)(CR≥10)(L/R/U/D) |
| tip lampa | 2S1PWLEDWithout Driver |
| interfață de semnal | CPU, 24 pins |
| tensiune de intrare | 3.3V (Typ.) |
| aplicarea | MPH |
