| PartNumber | TM028LDZ09 |
| Marca | Tianma |
| mărimea | 2.8 |
| Aplicație | MPH |
| Rezoluţie | 240×400 |
| Compoziţie | LCM |
| Luminozitate | 240 |
| CR | 450:1 |
| Culori | 65K/262K |
| Iluminare de fundal | WLED |
| Interfață | CPU |
| marca panoului | TIANMA |
| model de panou | TM028LDZ09 |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 2.8 inch |
| rezoluţie | 240(RGB)×400 , WQVGA |
| modul de afișare | TN, Normally White, Transmissive |
| Zonă activă | 36.72×61.2 mm |
| contur | 42×72.8 mm |
| suprafaţă | |
| luminozitatea | 240 cd/m² (Typ.) |
| Raport de contrast | 450:1 (Typ.) |
| culorile afișajului | 65K/262K , CIE193156% |
| timp de raspuns | 25 (Typ.)(Tr+Td) |
| unghi de vedere | 60/60/40/60 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | 1S4PWLEDWithout Driver |
| interfață de semnal | CPU, 39 pins |
| tensiune de intrare | (1.8/2.8)/2.8V (Typ.)(VDDIO/VDD) |
| aplicarea | MPH |
