| PartNumber | LS026B8PX04 |
| Marca | SHARP |
| mărimea | 2.6 |
| Aplicație | MPH |
| Rezoluţie | 240×400 |
| Compoziţie | LCM |
| Luminozitate | 180 |
| CR | 330:1 |
| Culori | 262K |
| Iluminare de fundal | WLED |
| Interfață | TTL |
| marca panoului | SHARP |
| model de panou | LS026B8PX04 |
| tip panou | CG-Silicon , LCM |
| dimensiunea panoului | 2.6 inch |
| rezoluţie | 240(RGB)×400 , WQVGA |
| modul de afișare | ASV, Normally Black, Transflective |
| Zonă activă | 33.84×56.4 mm |
| contur | 40.6×65.7 mm |
| suprafaţă | Hard coating (3H) |
| luminozitatea | 180 cd/m² (Typ.) |
| Raport de contrast | 330:1 (Typ.)(Transmissive)10:1 (Typ.)(Reflective) |
| culorile afișajului | 262K , CIE193172% |
| timp de raspuns | 13/30 (Typ.)(Tr/Td) |
| unghi de vedere | 80/80/80/80 (Typ.)(CR≥5)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | 1S5PWLEDWithout Driver |
| interfață de semnal | Parallel RGB (1 ch, 4-bit), 29 pins |
| tensiune de intrare | 10.6/-5.3V (Typ.)(VDD/GVSS) |
| aplicarea | MPH |
