| PartNumber | AMS465GS53 |
| Marca | Samsung |
| mărimea | 4.7 |
| Aplicație | MPH |
| Rezoluţie | 720×1280 |
| Compoziţie | Assembly |
| Luminozitate | 300 |
| CR | 3400:1 |
| Culori | 16.7M |
| Iluminare de fundal | self |
| Interfață | MIPI |
| marca panoului | SAMSUNG |
| model de panou | AMS465GS53 |
| tip panou | AM-OLED , Assembly |
| dimensiunea panoului | 4.7 inch |
| rezoluţie | 720RG(BG)×1280 , WXGA |
| Zonă activă | 57.96×103.04 mm |
| contur | 66.36×131.8 mm |
| suprafaţă | Hard coating |
| luminozitatea | 300 cd/m² (Typ.) |
| Raport de contrast | 3400 : 1 (Min.) |
| culorile afișajului | 16.7M (8-bit), CIE1931100% |
| unghi de vedere | 80/80/80/80 (Min.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| interfață de semnal | MIPI (4 data lanes), 44 pins |
| tensiune de intrare | 2.2/3.1/3.8V (Typ.)(VDD3/VCI/VBAT) |
| aplicarea | MPH |
| A047FW01 V0 | AUO | 4.7 | 480×272 |
| AMS465GS53 | Samsung | 4.7 | 720×1280 |
| AMS470GS16-1 | Samsung | 4.7 | 720×1280 |
| DMF50081NB-FW | Kyocera | 4.7 | 320×240 |
| H466TAN01.1 | AUO | 4.7 | 720×1280 |
| KCG047QV1AA-A21 | Kyocera | 4.7 | 320×240 |
| LH470WX6-SJ11 | LG Display | 4.7 | 750×1334 |
| LM32K10 | SHARP | 4.7 | 320×240 |
| LS047T1SC02 | SHARP | 4.7 | 1080×1920 |
| PG320240C | Other | 4.7 | 320×240 |
| H020HD01 V0 | AUO | 2.0 | 176×220 |
| LH550WF4-SJ11 | LG Display | 5.5 | 1080×1920 |
| LQ055T3SX04 | SHARP | 5.5 | 1080×1920 |
| LS050T1SX10 | SHARP | 5.0 | 1080×1920 |
| LS063K3SX54 | SHARP | 6.3 | 720×1280 |
| LT031MDZ4000 | JDI | 3.1 | 720×720 |
| LTP283QV-F03 | Samsung | 2.8 | 240×320 |
| LTS220QC-F0J | Samsung | 2.2 | 176×220 |
| TD028STEB2 | TPO | 2.8 | 240×320 |
| TM035PDZ00 | Tianma | 3.5 | 320×480 |
