| PartNumber | H466TAN01.1 |
| Marca | AUO |
| mărimea | 4.7 |
| Aplicație | MPH |
| Rezoluţie | 720×1280 |
| Compoziţie | CELL |
| Luminozitate | 0 |
| CR | 1000:1 |
| Culori | 16.7M |
| Iluminare de fundal | No B/L |
| Interfață | |
| marca panoului | AUO |
| model de panou | H466TAN01.1 |
| tip panou | LTPS TFT-LCD , CELL |
| dimensiunea panoului | 4.7 inch |
| rezoluţie | 720(RGB)×1280 , WXGA |
| modul de afișare | AHVA, Normally Black, Transmissive |
| Zonă activă | 58.104×103.296 mm |
| contur | 60.9×111.87 mm |
| suprafaţă | Hard coating |
| adâncimea sticlei | 0.17+0.17 mm |
| transmisivitatea | 3.9% (Typ.)(with Polarizer) |
| Raport de contrast | 1000:1 (Typ.) |
| culorile afișajului | 16.7M (8-bit), CIE193166% |
| timp de raspuns | 35 (Max.)(Tr+Td) |
| unghi de vedere | 80/80/80/80 (Typ.)(CR≥100)(L/R/U/D) |
| driver ic | COG Built-in NT35590 |
| aplicarea | MPH |
