| PartNumber | ACX502BMU-7 |
| Marca | SONY |
| mărimea | 3.5 |
| Aplicație | PDA |
| Rezoluţie | 240×320 |
| Compoziţie | LCM |
| Luminozitate | 70 |
| CR | 80:1 |
| Culori | 262K |
| Iluminare de fundal | WLED |
| Interfață | TTL |
| marca panoului | SONY |
| model de panou | ACX502BMU-7 |
| tip panou | LTPS TFT-LCD , LCM |
| dimensiunea panoului | 3.5 inch |
| rezoluţie | 240(RGB)×320 , QVGA |
| modul de afișare | TN, Normally White, Transflective |
| suprafaţă | Hard coating (3H) |
| luminozitatea | 70 cd/m² (Typ.) |
| Raport de contrast | 80:1 (Typ.)(Transmissive)7:1 (Typ.)(Reflective) |
| culorile afișajului | 262K (6-bit) |
| timp de raspuns | |
| unghi de vedere | |
| frecvență | 60Hz |
| tip lampa | 6 pcsWLEDWithout Driver |
| interfață de semnal | Parallel RGB (1 ch, 6-bit) |
| tensiune de intrare | 3.0/5.0V (Typ.)(VDD1/VDD2) |
| rohs: | |
| aplicarea | PDA |
