| PartNumber | C035QVN01.0 |
| Marca | AUO |
| mărimea | 3.5 |
| Aplicație | CNS |
| Rezoluţie | 240×320 |
| Compoziţie | LCM |
| Luminozitate | 450 |
| CR | 1000:1 |
| Culori | 262K |
| Iluminare de fundal | WLED |
| Interfață | TTL |
| marca panoului | AUO |
| model de panou | C035QVN01.0 |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 3.5 inch |
| rezoluţie | 240(RGB)×320 , QVGA |
| modul de afișare | AMVA, Normally Black, Transmissive |
| Zonă activă | 53.28×71.04 mm |
| contur | 69.22×87.2×21 mm |
| suprafaţă | Antiglare |
| luminozitatea | 450 cd/m² (Typ.) |
| Raport de contrast | 1000:1 (Min.) |
| culorile afișajului | 262K (6-bit), CIE193170% |
| timp de raspuns | 10/25 (Typ.)(Tr/Td) |
| unghi de vedere | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | 2S2PWLEDWithout Driver |
| interfață de semnal | Parallel RGB (1 ch, 6-bit), 50 pins |
| tensiune de intrare | 3.3V (Typ.) |
| aplicarea | CNS |
