| PartNumber | COM35H3P09UTC |
| Marca | ORTUSTECH |
| mărimea | 3.5 |
| Aplicație | HHP |
| Rezoluţie | 480×640 |
| Compoziţie | LCM |
| Luminozitate | 200 |
| CR | 600:1 |
| Culori | 262K |
| Iluminare de fundal | WLED |
| Interfață | TTL |
| marca panoului | ORTUSTECH |
| model de panou | COM35H3P09UTC 1 Compatible model |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 3.5 inch |
| rezoluţie | 480(RGB)×640 , VGA |
| modul de afișare | Buenaview, Normally Black, Transflective |
| Zonă activă | 53.28×71.04 mm |
| contur | 63.5×85×5.83 mm |
| suprafaţă | Hard coating (3H) |
| luminozitatea | 200 cd/m² (Typ.) |
| Raport de contrast | 600:1 (Typ.)(Transmissive)5.5:1 (Typ.)(Reflective) |
| culorile afișajului | 262K (6-bit) |
| timp de raspuns | 40/60 (Max.)(Tr/Td) |
| unghi de vedere | 80/80/80/80 (Min.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | 6S1PWLEDWithout Driver |
| interfață de semnal | Parallel RGB (1 ch, 6-bit), 39 pins |
| tensiune de intrare | 3.0/1.8V (Typ.)(VDD/VCCIO) |
| aplicarea | HHP |
| 35WVF1H | SII | 3.5 | 480×800 |
| AMS347FF02 | Samsung | 3.5 | 360×640 |
| COM35H3M10XTC | ORTUSTECH | 3.5 | 240×320 |
| COM35H3M74UTC | ORTUSTECH | 3.5 | 480×640 |
| COM35H3P09UTC | ORTUSTECH | 3.5 | 480×640 |
| H347QVN02.0 | AUO | 3.5 | 320×480 |
| LQ035Q1DH02 | SHARP | 3.5 | 320×240 |
| LQ035Q5DG01 | SHARP | 3.5 | 320×240 |
| PD035QX1 | E Ink | 3.5 | 240×320 |
| PT035TN23 V.3 | Innolux | 3.5 | 320×240 |
| COM32H3N74ULC | ORTUSTECH | 3.2 | 480×800 |
| DLC0090AZG | Other | 0.91 | 80×160 |
| G043FTT01.0 | AUO | 4.3 | 480×272 |
| LM038QC1R10 | SHARP | 3.8 | 320×240 |
| LQ038B7DB01 | SHARP | 3.8 | 320×480 |
| LQ043T1DG28 | SHARP | 4.3 | 480×272 |
| LS024Q3UX12(G) | SHARP | 2.4 | 320×240 |
| LS037V7DW03 | SHARP | 3.7 | 480×640 |
| TM030LDHT2 | Tianma | 3.0 | 240×400 |
| TX09D30VM1CCA | KOE | 3.5 | 240×320 |
