| PartNumber | TX09D30VM1CCA |
| Marca | KOE |
| mărimea | 3.5 |
| Aplicație | HHP |
| Rezoluţie | 240×320 |
| Compoziţie | LCM |
| Luminozitate | 250 |
| CR | 300:1 |
| Culori | 262K |
| Iluminare de fundal | WLED |
| Interfață | TTL |
| marca panoului | HITACHI |
| model de panou | TX09D30VM1CCA |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 3.5 inch |
| rezoluţie | 240(RGB)×320 , QVGA |
| modul de afișare | TN, Normally White, TMR |
| Zonă activă | 53.64×71.52 mm |
| contur | 64×86×7.9 mm |
| suprafaţă | Antiglare |
| luminozitatea | 250 cd/m² (Typ.) |
| Raport de contrast | 300 : 1 (Typ.) |
| culorile afișajului | 262K (6-bit), CIE193150% |
| timp de raspuns | 15/15 (Typ.)(Tr/Td) |
| unghi de vedere | 70/70/80/60 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | WLEDEmbedded (LED Driver) |
| interfață de semnal | CMOS (1 ch, 6-bit), 40 pins |
| tensiune de intrare | 3.3V (Typ.) |
| aplicarea | HHP |
| A035QN05 V1 | AUO | 3.5 | 320×240 |
| EL160.80.50 ET CC | Lumineq | 3.5 | 160×80 |
| LQ035Q3DG02A | SHARP | 3.5 | 320×240 |
| LQ035Q7DB03F | SHARP | 3.5 | 240×320 |
| LTV350QV-F09 | Samsung | 3.5 | 320×240 |
| NL2432DR22-02B | NLT | 3.5 | 240×320 |
| NL2432HC22-40J | NLT | 3.5 | 240×320 |
| NL2432HC22-41K | NLT | 3.5 | 240×320 |
| T-55343GD035JU-LW-AFN | Kyocera | 3.5 | 320×240 |
| TX09D30VM1CCA | KOE | 3.5 | 240×320 |
| 28QVF1H | SII | 2.8 | 240×320 |
| 35HVE1H | SII | 3.5 | 320×480 |
| 35WVF0H | SII | 3.5 | 480×800 |
| DLC0240ACOG-3 | Other | 2.4 | 240×320 |
| LQ035Q3DG01 | SHARP | 3.5 | 320×240 |
| LQ035Q7DB03F | SHARP | 3.5 | 240×320 |
| LQ040Y3DX80 | SHARP | 4.0 | 480×800 |
| LQ043T1DG03 | SHARP | 4.3 | 480×272 |
| LS037V7DW03A | SHARP | 3.7 | 480×640 |
| TM030LDHT2 | Tianma | 3.0 | 240×400 |
