| PartNumber | 35WVF0H |
| Marca | SII |
| mărimea | 3.5 |
| Aplicație | HHP |
| Rezoluţie | 480×800 |
| Compoziţie | LCM |
| Luminozitate | 300 |
| CR | 800:1 |
| Culori | 16.2M |
| Iluminare de fundal | WLED |
| Interfață | TTL |
| marca panoului | SII |
| model de panou | 35WVF0H |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 3.5 inch |
| rezoluţie | 480(RGB)×800 , WVGA |
| modul de afișare | FFS, Normally Black, Transmissive |
| Zonă activă | 45.36×75.6 mm |
| contur | 51.46×90.55 mm |
| suprafaţă | Clear, Hard coating |
| luminozitatea | 300 cd/m² (Typ.) |
| Raport de contrast | 800:1 (Typ.) |
| culorile afișajului | 16.2M (6-bit + Dithering), CIE193170% |
| timp de raspuns | 35 (Typ.)(Tr+Td) |
| unghi de vedere | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| tip lampa | 6S1PWLED |
| interfață de semnal | Parallel RGB (1 ch, 6/8-bit) + SPI, 61 pins |
| aplicarea | HHP |
