| PartNumber | LQ038B7DB01 |
| Marca | SHARP |
| mărimea | 3.8 |
| Aplicație | HHP |
| Rezoluţie | 320×480 |
| Compoziţie | LCM |
| Luminozitate | |
| CR | 60:1 |
| Culori | 262K |
| Iluminare de fundal | No B/L |
| Interfață | TTL |
| marca panoului | SHARP |
| model de panou | LQ038B7DB01 |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 3.8 inch |
| rezoluţie | 320(RGB)×480 , HVGA |
| modul de afișare | TN, Normally White, Transflective |
| Zonă activă | 52.8×79.2 mm |
| contur | 64.9×92.3 mm |
| suprafaţă | Clear, Hard coating |
| luminozitatea | |
| Raport de contrast | 60:1 (Typ.)(Transmissive)8:1 (Typ.)(Reflective) |
| culorile afișajului | 262K (6-bit) |
| timp de raspuns | 20/35 (Typ.)(Tr/Td) |
| unghi de vedere | 40/40/40/50 (Typ.)(CR≥2)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | No B/L |
| interfață de semnal | Parallel RGB (1 ch, 6-bit), 39 pins |
| tensiune de intrare | 4.8/3.3/13.0/-10.0V (Typ.)(VSHA/VSHD/VDD/VEE) |
| aplicarea | HHP |
