| PartNumber | NL12876AC39-01 |
| Marca | NLT |
| mărimea | 23.0 |
| Aplicație | DMPC |
| Rezoluţie | 1280×768 |
| Compoziţie | LCM |
| Luminozitate | 450 |
| CR | 350:1 |
| Culori | 16.7M |
| Iluminare de fundal | CCFL |
| Interfață | LVDS |
| marca panoului | NEC |
| model de panou | NL12876AC39-01 |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 23.0 inch |
| rezoluţie | 1280(RGB)×768 , WXGA |
| modul de afișare | UA-SFT, Normally Black, Transmissive |
| Zonă activă | 501.12×300.672 mm |
| contur | 528×326 mm |
| suprafaţă | Hard coating (2H), Antireflection |
| luminozitatea | 450 cd/m² (Typ.) |
| Raport de contrast | 350:1 (Typ.) |
| culorile afișajului | 16.7M (8-bit), CIE193172% |
| timp de raspuns | 10/13 (Typ.)(Tr/Td) |
| unghi de vedere | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | 12 pcsCCFLEmbedded (Inverter) |
| interfață de semnal | LVDS (1 ch, 8-bit), 20 pins |
| tensiune de intrare | 5.0V (Typ.) |
| aplicarea | DMPC |
