| PartNumber | MT190EN02 V.Y |
| Marca | Innolux |
| mărimea | 19.0 |
| Aplicație | DMPC |
| Rezoluţie | 1280×1024 |
| Compoziţie | LCM |
| Luminozitate | 250 |
| CR | 1000:1 |
| Culori | 16.7M |
| Iluminare de fundal | CCFL |
| Interfață | LVDS |
| marca panoului | INNOLUX |
| model de panou | MT190EN02 V.Y |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 19.0 inch |
| rezoluţie | 1280(RGB)×1024 , SXGA |
| modul de afișare | TN, Normally White, Transmissive |
| Zonă activă | 376.32×301.06 mm |
| contur | 396×324×16.5 mm |
| suprafaţă | Antiglare (Haze 25%), Hard coating (3H) |
| luminozitatea | 250 cd/m² (Typ.) |
| Raport de contrast | 1000:1 (Typ.) |
| culorile afișajului | 16.7M (6-bit + Hi-FRC), CIE193172% |
| timp de raspuns | 1.5/3.5 (Typ.)(Tr/Td) |
| unghi de vedere | 85/85/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | 2 pcsCCFLWithout Driver |
| interfață de semnal | LVDS (2 ch, 8-bit), 30 pins |
| tensiune de intrare | 5.0V (Typ.) |
| aplicarea | DMPC |
| G190EG01 V0 | AUO | 19.0 | 1280×1024 |
| G190EG01 V2 | AUO | 19.0 | 1280×1024 |
| LM190E08-TLG4 | LG Display | 19.0 | 1280×1024 |
| M190A1-L07 | Innolux | 19.0 | 1440×900 |
| M190EG01 V2 | AUO | 19.0 | 1280×1024 |
| M190EN03 V2 | AUO | 19.0 | 1280×1024 |
| M190EN04 V5 | AUO | 19.0 | 1280×1024 |
| M190PW01 V8 | AUO | 19.0 | 1440×900 |
| MT190EN02 V.W | Innolux | 19.0 | 1280×1024 |
| MT190EN02 V.Y | Innolux | 19.0 | 1280×1024 |
| LM220WE1-TLB3 | LG Display | 22.0 | 1680×1050 |
| LM230WF2-SLA2 | LG Display | 23.0 | 1920×1080 |
| LTM181E3-P01 | Samsung | 18.1 | 1280×1024 |
| LTM190E4-L03 | Samsung | 19.0 | 1280×1024 |
| M200RW01 V6 | AUO | 20.0 | 1600×900 |
| M270HW02 V0 | AUO | 27.0 | 1920×1080 |
| MV215FHM-N30 | BOE | 21.5 | 1920×1080 |
| NL128102BC23-03 | NLT | 15.4 | 1280×1024 |
| NL128102BC29-01 | NLT | 19.0 | 1280×1024 |
| SVA156WX1-01TB | SVA-NEC | 15.6 | 1366×768 |
