| PartNumber | M190EG01 V2 |
| Marca | AUO |
| mărimea | 19.0 |
| Aplicație | IA |
| Rezoluţie | 1280×1024 |
| Compoziţie | LCM |
| Luminozitate | 300 |
| CR | 2000:1 |
| Culori | 16.7M |
| Iluminare de fundal | CCFL |
| Interfață | LVDS |
| marca panoului | AUO |
| model de panou | M190EG01 V2 1 Compatible model |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 19.0 inch |
| rezoluţie | 1280(RGB)×1024 , SXGA |
| modul de afișare | MVA, Normally Black, Transmissive |
| Zonă activă | 376.32×301.056 mm |
| contur | 396×324×17.53 mm |
| suprafaţă | Antiglare, Hard coating (3H) |
| luminozitatea | 300 cd/m² (Typ.) |
| Raport de contrast | 2000:1 (Typ.) |
| culorile afișajului | 16.7M (6-bit + Hi-FRC) |
| timp de raspuns | 15/5 (Typ.)(Tr/Td); 8 (Typ.)(G to G) |
| unghi de vedere | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | 4 pcsCCFLWithout Driver |
| interfață de semnal | LVDS (2 ch, 8-bit), 30 pins |
| tensiune de intrare | 5.0V (Typ.) |
| aplicarea | IA |
| M190EG01 V0 | AUO | 19.0 | 1280×1024 |
| M190EG01 V2 | AUO | 19.0 | 1280×1024 |
| M190EG01 V3 | AUO | 19.0 | 1280×1024 |
| M190EG02 V4 | AUO | 19.0 | 1280×1024 |
| M190EG02 V7 | AUO | 19.0 | 1280×1024 |
| M190EG02 V9 | AUO | 19.0 | 1280×1024 |
| M190EN03 V0 | AUO | 19.0 | 1280×1024 |
| M190EN03 V2 | AUO | 19.0 | 1280×1024 |
| M190EN04 V1 | AUO | 19.0 | 1280×1024 |
| M190ETN01.0 | AUO | 19.0 | 1280×1024 |
| AC150XA02 | Mitsubishi | 15.0 | 1024×768 |
| G150XTN03.2 | AUO | 15.0 | 1024×768 |
| G170EG01 V0 | AUO | 17.0 | 1280×1024 |
| LQ190E1LW42 | SHARP | 19.0 | 1280×1024 |
| LTA084C190F | TOSHIBA | 8.4 | 800×600 |
| NL6448AC33-15 | NLT | 10.4 | 640×480 |
| PD104SL5 | E Ink | 10.4 | 800×600 |
| TCG035QVLPDANN-GN50 | Kyocera | 3.5 | 320×240 |
| UG-2864ASYCG01 | WiseChip | 1.54 | 128×64 |
| UG-2864KLBLG01 | WiseChip | 1.3 | 128×64 |
