| PartNumber | G170EG01 V0 |
| Marca | AUO |
| mărimea | 17.0 |
| Aplicație | IA |
| Rezoluţie | 1280×1024 |
| Compoziţie | LCM |
| Luminozitate | 380 |
| CR | 1000:1 |
| Culori | 16.7M |
| Iluminare de fundal | CCFL |
| Interfață | LVDS |
| marca panoului | AUO |
| model de panou | G170EG01 V0 |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 17.0 inch |
| rezoluţie | 1280(RGB)×1024 , SXGA |
| modul de afișare | TN, Normally White, Transmissive |
| Zonă activă | 337.92×270.336 mm |
| contur | 358.5×296.5×15.8 mm |
| suprafaţă | Antiglare, Hard coating (3H) |
| luminozitatea | 380 cd/m² (Typ.) |
| Raport de contrast | 1000:1 (Typ.) |
| culorile afișajului | 16.7M (6-bit + Hi-FRC), CIE193172% |
| timp de raspuns | 3.5/1.5 (Typ.)(Tr/Td) |
| unghi de vedere | 85/85/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | 4 pcsCCFLWithout Driver |
| interfață de semnal | LVDS (2 ch, 8-bit), 30 pins |
| tensiune de intrare | 5.0V (Typ.) |
| aplicarea | IA |
| B170PW02 V0 | AUO | 17.0 | 1440×900 |
| B170PW03 V4 | AUO | 17.0 | 1440×900 |
| B170PW07 V0 | AUO | 17.0 | 1440×900 |
| G170EG01 V0 | AUO | 17.0 | 1280×1024 |
| G170EG01 V1 | AUO | 17.0 | 1280×1024 |
| G170ETN01.0 | AUO | 17.0 | 1280×1024 |
| G170ETN02.0 | AUO | 17.0 | 1280×1024 |
| LM170E03-TLG1 | LG Display | 17.0 | 1280×1024 |
| LTM170E4-P01 | Samsung | 17.0 | 1280×1024 |
| M170EG01 V0 | AUO | 17.0 | 1280×1024 |
| EL320.240.36 IN | Lumineq | 5.7 | 320×240 |
| G190ETN01.2 | AUO | 19.0 | 1280×1024 |
| LB104S01-TL01 | LG Display | 10.4 | 800×600 |
| LM641836R | SHARP | 9.4 | 640×480 |
| LTM08C351L | TOSHIBA | 8.4 | 800×600 |
| NL6448BC26-09C | NLT | 8.4 | 640×480 |
| NL6448BC33-20 | NLT | 10.4 | 640×480 |
| RGS32256064YH001 | RiTdisplay | 3.2 | 256×64 |
| TM084SBHG04 | Tianma | 8.4 | 800×600 |
| UMSH-8377MD-8T | Other | 5.7 | 640×480 |
