| PartNumber | NL12876BC26-28 |
| Marca | NLT |
| mărimea | 15.3 |
| Aplicație | IA |
| Rezoluţie | 1280×768 |
| Compoziţie | LCM |
| Luminozitate | 330 |
| CR | 1000:1 |
| Culori | 16.7M |
| Iluminare de fundal | CCFL |
| Interfață | LVDS |
| marca panoului | NEC |
| model de panou | NL12876BC26-28 |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 15.3 inch |
| rezoluţie | 1280(RGB)×768 , WXGA |
| modul de afișare | UA-SFT, Normally Black, Transmissive |
| Zonă activă | 334.08×200.45 mm |
| contur | 358×226 mm |
| suprafaţă | Antiglare, Hard coating (3H) |
| luminozitatea | 330 cd/m² (Typ.) |
| Raport de contrast | 1000:1 (Typ.) |
| culorile afișajului | 16.7M (6-bit + Hi-FRC), CIE193172% |
| timp de raspuns | 14/11 (Typ.)(Tr/Td) |
| unghi de vedere | 88/88/88/88 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | 4 pcsCCFLWithout Driver |
| interfață de semnal | LVDS (1 ch, 8-bit), 20 pins |
| tensiune de intrare | 3.3V (Typ.) |
| aplicarea | IA |
