| PartNumber | NL12876BC15-01 |
| Marca | NLT |
| mărimea | 8.9 |
| Aplicație | NBPC |
| Rezoluţie | 1280×768 |
| Compoziţie | LCM |
| Luminozitate | 280 |
| CR | 500:1 |
| Culori | 262K |
| Iluminare de fundal | WLED |
| Interfață | LVDS |
| marca panoului | NEC |
| model de panou | NL12876BC15-01 |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 8.9 inch |
| rezoluţie | 1280(RGB)×768 , WXGA |
| modul de afișare | TN, Normally White, Transmissive |
| Zonă activă | 193.92×116.352 mm |
| contur | 209.2×130.3×7.7 mm |
| suprafaţă | Clear, Hard coating (3H) |
| luminozitatea | 280 cd/m² (Typ.) |
| Raport de contrast | 500:1 (Typ.) |
| culorile afișajului | 262K (6-bit), CIE193156% |
| timp de raspuns | 6/2 (Typ.)(Tr/Td) |
| unghi de vedere | 45/45/20/40 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | 11S3PWLEDWithout Driver |
| interfață de semnal | LVDS (1 ch, 6-bit), 30 pins |
| tensiune de intrare | 3.3V (Typ.) |
| aplicarea | NBPC |
| LJ640U34 | SHARP | 8.9 | 640×400 |
| LSUGC202XA | ALPS | 8.9 | 640×240 |
| LTL089CL02-002 | Samsung | 8.9 | 1920×1200 |
| LTM09C362F | TOSHIBA | 8.9 | 1024×600 |
| NL12876AC18-03 | NLT | 10.6 | 1280×768 |
| NL12876AC18-03D | NLT | 10.6 | 1280×768 |
| NL12876AC39-01 | NLT | 23.0 | 1280×768 |
| NL12876BC15-01 | NLT | 8.9 | 1280×768 |
| NL12876BC26-25 | NLT | 15.3 | 1280×768 |
| NL12876BC26-28 | NLT | 15.3 | 1280×768 |
| B133XTN01.5 | AUO | 13.3 | 1366×768 |
| B141EW04 V3 | AUO | 14.1 | 1280×800 |
| LP104S2 | LG Display | 10.4 | 800×600 |
| LP156WHA-SLA2 | LG Display | 15.6 | 1366×768 |
| LP171WP6-TL04 | LG Display | 17.1 | 1440×900 |
| LTM10C353 | TOSHIBA | 10.0 | 1280×600 |
| LTN141AT09-101 | Samsung | 14.1 | 1280×800 |
| LTN156AT30-W01 | Samsung | 15.6 | 1366×768 |
| M133NWN1 R3 | IVO | 13.3 | 1366×768 |
| N170C3-L01 | Innolux | 17.0 | 1440×900 |
