| PartNumber | LTL101DL03-T01 |
| Marca | Samsung |
| mărimea | 10.1 |
| Aplicație | PAD |
| Rezoluţie | 2560×1600 |
| Compoziţie | LCM |
| Luminozitate | 370 |
| CR | 800:1 |
| Culori | 16.2M |
| Iluminare de fundal | WLED |
| Interfață | eDP |
| marca panoului | SAMSUNG |
| model de panou | LTL101DL03-T01 |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 10.1 inch |
| rezoluţie | 2560RG(BW)×1600 , WQXGA |
| modul de afișare | PLS, Normally Black, Transmissive |
| Zonă activă | 216.576×135.36 mm |
| contur | 232.22×156.92×5.2 mm |
| suprafaţă | Glare (Haze 0%), Hard coating (2H) |
| luminozitatea | 370 cd/m² (Typ.) |
| Raport de contrast | 800:1 (Typ.) |
| culorile afișajului | 16.2M (6-bit + FRC) |
| timp de raspuns | 16 (Typ.)(Tr+Td) |
| unghi de vedere | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | 7S6PWLEDEmbedded (LED Driver) |
| interfață de semnal | eDP (4 Lanes), 45 pins |
| tensiune de intrare | 3.3V (Typ.) |
| aplicarea | PAD |
