| PartNumber | HSD100IXN1-A00 |
| Marca | HannStar |
| mărimea | 10.0 |
| Aplicație | DPF |
| Rezoluţie | 1024×768 |
| Compoziţie | LCM |
| Luminozitate | 250 |
| CR | 600:1 |
| Culori | 262K |
| Iluminare de fundal | WLED |
| Interfață | TTL |
| marca panoului | HannStar |
| model de panou | HSD100IXN1-A00 |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 10.0 inch |
| rezoluţie | 1024(RGB)×768 , XGA |
| modul de afișare | TN, Normally White, Transmissive |
| Zonă activă | 202.752×152.064 mm |
| contur | 215.5×166.5 mm |
| suprafaţă | Antiglare, Hard coating (3H) |
| luminozitatea | 250 cd/m² (Typ.) |
| Raport de contrast | 600:1 (Typ.) |
| culorile afișajului | 262K (6-bit) |
| timp de raspuns | 2.4/5.6(Typ.)(Tr/Td) |
| unghi de vedere | 75/75/60/70 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | 3S11PWLEDWithout Driver |
| interfață de semnal | TTL (1 ch, 6-bit), 60 pins |
| tensiune de intrare | 3.3/9.48/17/-7V (Typ.)(VCC/AVDD/VGH/VGL) |
| aplicarea | DPF |
| HSD100IFW1-A00 | HannStar | 10.1 | 1024×600 |
| HSD100IFW1-A02 | HannStar | 10.1 | 1024×600 |
| HSD100IFW1-A04 | HannStar | 10.1 | 1024×600 |
| HSD100IFW1-C01 | HannStar | 10.1 | 1024×600 |
| HSD100IFW1-F01 | HannStar | 10.1 | 1024×600 |
| HSD100IFW1-F03 | HannStar | 10.1 | 1024×600 |
| HSD100IFW3-A00 | HannStar | 10.1 | 1024×600 |
| HSD100IFW4-A00 | HannStar | 10.1 | 1024×600 |
| HSD100IXN1-A00 | HannStar | 10.0 | 1024×768 |
| TM100SV-A02-01 | SANYO | 10.0 | 800×600 |
| A080SN01 V0 | AUO | 8.0 | 800×600 |
| AT070TN84 | Innolux | 7.0 | 800×480 |
| CLAA080LA0ACW | CPT | 8.0 | 800×480 |
| DLC0700OZG-T-1 | Other | 7.0 | 800×480 |
| HSD070IDW1-A20 | HannStar | 7.0 | 800×480 |
| HSD100IFW1-A04 | HannStar | 10.1 | 1024×600 |
| HSD100IFW1-F01 | HannStar | 10.1 | 1024×600 |
| PM070WX1 | E Ink | 7.0 | 800×480 |
| TM070RDH10 | Tianma | 7.0 | 800×480 |
| TX31D50VM2BAA | KOE | 12.0 | 800×480 |
