| PartNumber | HSD070ISN1-D00 |
| Marca | HannStar |
| mărimea | 7.0 |
| Aplicație | DPF |
| Rezoluţie | 800×600 |
| Compoziţie | LCM |
| Luminozitate | 350 |
| CR | 600:1 |
| Culori | 16.7M |
| Iluminare de fundal | WLED |
| Interfață | TTL |
| marca panoului | HannStar |
| model de panou | HSD070ISN1-D00 |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 7.0 inch |
| rezoluţie | 800(RGB)×600 , SVGA |
| modul de afișare | TN, Normally White, Transmissive |
| Zonă activă | 141.6×106.2 mm |
| contur | 156.4×122.25×4.4 mm |
| suprafaţă | Antiglare, Hard coating (3H) |
| luminozitatea | 350 cd/m² (Typ.) |
| Raport de contrast | 600:1 (Typ.) |
| culorile afișajului | 16.7M (6-bit + Hi-FRC), CIE193150% |
| timp de raspuns | 2.4/5.6 (Typ.)(Tr/Td) |
| unghi de vedere | 60/70/75/75 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | 2S5PWLEDWithout Driver |
| interfață de semnal | Parallel RGB (1 ch, 8-bit), 60 pins |
| tensiune de intrare | 3.3/9.5/16.5/-10V (Typ.)(VCC/AVDD/VGH/VGL) |
| aplicarea | DPF |
