| PartNumber | HSD070BHW1-A00 |
| Marca | HannStar |
| mărimea | 7.0 |
| Aplicație | Pad & Tablet |
| Rezoluţie | 720×1280 |
| Compoziţie | CELL , a-Si TFT-LC |
| Luminozitate | |
| CR | 800:1 |
| Culori | 16.7M |
| Iluminare de fundal | No |
| Interfață | |
| producător | HannStar |
| marimea ecranului | 7.0 inch |
| numărul de pixeli | 720(RGB)×1280 (WXGA) 210PPI |
| zona activa (mm) | 86.94 × 154.56 (H×V) |
| luminanţă | 0 cd/m² |
| unghi de vedere | 80/80/80/80 (Typ.)(CR≥10) |
| vedere buna la | Symmetry |
| grosimea sticlei | 0.40+0.40 mm |
| adâncimea culorii | 16.7M 70% NTSC |
| masa | - |
| rată de reîmprospătare | - |
| lista de drivere ic | Built-in COG HX8394-A01, HX8394-B, NT35520, NT35521, OTM1283A, OTM1288A |
| max. evaluări | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
| numele modelului | HSD070BHW1-A00 |
| tipul de ecran | CELL , a-Si TFT-LCD |
| aranjament | RGB Ttilt Stripe |
| contur (mm) | 89.94 × 162.56 × 0.8 (H×V×D) |
| Raport de contrast | 800 : 1 (Typ.) (TM) |
| raspuns | 10/20 (Typ.)(Tr/Td) ms |
| modul de lucru | IPS Pro, Normally Black, Transmissive |
| transmisivitatea | 4.0% (Typ.)(with Polarizer) |
| lumina de fundal | No B/L |
| folosit pentru | Pad & Tablet |
| touch screen | Without |
