| PartNumber | A070XN01 V0 |
| Marca | AUO |
| mărimea | 7.0 |
| Aplicație | |
| Rezoluţie | 1024×768 |
| Compoziţie | LCM |
| Luminozitate | 330 |
| CR | 800:1 |
| Culori | 16.2M |
| Iluminare de fundal | WLED |
| Interfață | LVDS |
| marca panoului | AUO |
| model de panou | A070XN01 V0 |
| tip panou | a-Si TFT-LCD , LCM |
| dimensiunea panoului | 7.0 inch |
| rezoluţie | 1024(RGB)×768 , XGA |
| modul de afișare | MVA, Normally Black, Transmissive |
| Zonă activă | 141.312×105.984 mm |
| contur | 154×119.2×3.5 mm |
| suprafaţă | Antiglare, Hard coating (3H) |
| luminozitatea | 330 cd/m² (Typ.) |
| Raport de contrast | 800:1 (Typ.) |
| culorile afișajului | 16.2M (6-bit + FRC), CIE193145% |
| timp de raspuns | 15/10 (Typ.)(Tr/Td) |
| unghi de vedere | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| tip lampa | 3S9PWLEDWithout Driver |
| interfață de semnal | LVDS (1 ch, 8-bit), 40 pins |
| tensiune de intrare | 3.3/5/-5V (Typ.)(VDDIO/VDPA/VDNA) |
