| PartNumber | H497TLB01.4 |
| Marca | AUO |
| mărimea | 5.0 |
| Aplicație | MPH |
| Rezoluţie | 720×1280 |
| Compoziţie | OLED |
| Luminozitate | 275 |
| CR | 10000:1 |
| Culori | 16.7M |
| Iluminare de fundal | self |
| Interfață | MIPI |
| marca panoului | AUO |
| model de panou | H497TLB01.4 |
| tip panou | AM-OLED , OLED |
| dimensiunea panoului | 5.0 inch |
| rezoluţie | 720(RGB)×1280 , WXGA |
| Zonă activă | 61.92×110.08 mm |
| contur | 65.92×118.64 mm |
| suprafaţă | |
| luminozitatea | 275 cd/m² (Typ.) |
| Raport de contrast | 10000 : 1 (Min.) |
| culorile afișajului | 16.7M (8-bit), CIE1931100% |
| unghi de vedere | 80/80/80/80 (Min.)(CR≥1600)(L/R/U/D) |
| frecvență | 60Hz |
| driver ic | Built-in RM69052 |
| interfață de semnal | MIPI (4 data lanes), 39 pins |
| tensiune de intrare | 1.8/3.1/3.7V (Typ.)(VDDI/VCI/VBAT) |
| aplicarea | MPH |
