| PartNumber | TMS190WX1-08TC |
| Marca | Tianma |
| mărimea | 19.0 |
| Aplicație | DMPC |
| Rezoluţie | 1440×900 |
| Compoziţie | CELL |
| Luminozitate | 0 |
| CR | 1000:1 |
| Culori | 16.7M |
| Iluminare de fundal | No B/L |
| Interfață | LVDS |
| marca panoului | AVIC |
| model de panou | TMS190WX1-08TC |
| tip panou | a-Si TFT-LCD , CELL |
| dimensiunea panoului | 19.0 inch |
| rezoluţie | 1440(RGB)×900 , WXGA+ |
| modul de afișare | TN, Normally White, Transmissive |
| Zonă activă | 408.24×255.15 mm |
| suprafaţă | |
| Raport de contrast | 1000:1 (Typ.) |
| culorile afișajului | 16.7M (6-bit + Hi-FRC), CIE193172% |
| timp de raspuns | 1.3/3.7 (Typ.)(Tr/Td) |
| unghi de vedere | 85/85/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frecvență | 60Hz |
| interfață de semnal | LVDS (2 ch, 8-bit), 30 pins |
| tensiune de intrare | 5.0V (Typ.) |
| aplicarea | DMPC |
| G190ETN01.1 | AUO | 19.0 | 1280×1024 |
| HSD190MEN3-A03 | HannStar | 19.0 | 1280×1024 |
| HT190WG3-101 | BOE | 19.0 | 1440×900 |
| LM190E08-TLG4 | LG Display | 19.0 | 1280×1024 |
| LM190E08-TLGD | LG Display | 19.0 | 1280×1024 |
| LM190E09-TLK1 | LG Display | 19.0 | 1280×1024 |
| P190MWW1-404 | IVO | 19.0 | 1440×900 |
| TM190MFS01 | Tianma | 19.0 | 1440×900 |
| TMS190WX1-05TB | Tianma | 19.0 | 1440×900 |
| TMS190WX1-08TC | Tianma | 19.0 | 1440×900 |
| HM185WX1-400 | BOE | 18.5 | 1366×768 |
| HM200WD1-100 | BOE | 20.0 | 1600×900 |
| HT185WX1-100 | BOE | 18.5 | 1366×768 |
| LM190E05-SL02 | LG Display | 19.0 | 1280×1024 |
| LM220WE1-TLB2 | LG Display | 22.0 | 1680×1050 |
| LTM150XO-L01 | Samsung | 15.0 | 1024×768 |
| M236HGE-L20 | Innolux | 23.6 | 1920×1080 |
| MT190AW02 V.Y | Innolux | 19.0 | 1440×900 |
| QD15XL13 Rev.01 | QDI | 15.0 | 1024×768 |
| TX38D14VC0CAA | KOE | 15.0 | 1024×768 |
